Keya 1000w 48v Bldc Motor Brushless Dc Motor Price

• Overview


1. Protection grade: IP55, insulation grade: F

2. Winding overhang structure optimization, to minimize the copper loss and iron loss minimization, small volume, light weight, low temperature rise, high efficiency
3. Super high coercivity, the maximum magnetic energy product NdFe35 permanent magnetic materials, strong resistance to demagnetization, motor performance is stable.
4. Low noise, low vibration, low moment of inertia.

5. High torque, fast dynamic response, wide speed range, strong overload capacity (four times)

Small Servo Motor Features
1. High Torque to inertia ratio&up to 25000Nm/kgm2
2. Fast dynamic response *time constant <20ms
3. Wide speed adjusting&feedback up to 1000:1
4. Steady speed precision up to 0.5%
5. High overload, 2Mn/30s,3 .5N.m/10s
6. Small volume and light
7. Silent,the lowest noise is only 45dB(A)

8. Protected with IP55,Class F insulation

Small Servo Motor Industry class
1.The altitude should be over 1000 meters above sea level
2.Environment temperature:-25℃~+50℃

3.The month average tallest relative humidity is 90%,at the same the month average lowest temperature is less than 25℃

48v 1000w high power small size bldc motor with hall sensor 3000rpm brushless dc motor bldc 3.2N.m

• Datasheet




Motor type	bldc motor encoder, servo motor, pmsm motor
Rated voltage	48V
Rated power	1000W
Rated speed	1500rpm
Rated torque	6.4N.m
Peak torque	19.2N.m
Number of poles	16
Encoder	optical, 2500ppr

• Connect cable




Notice: the standard motor don't have brake, if you need brake, kindly advise.

• Related servo motor







Model	Volts	Power	RPM	Rated torque	Peak torque	frame
KY80AS0404-30-3P	48V	400W	3000	1.27N.m	3.8N.m	80mm
KY80AS0407-30-3P	48V	700W	3000	2.4N.m	7.1N.m
KY80AS0410-30-3P	48V	1000W	3000	3.2N.m	9.6N.m
KY80AS0202-15	24V	200w	1500	1.27N.m	3.8N.m
KY80AS0402-15	48V	200w	1500	1.27N.m	3.8N.m
KY80AS0204-15	24V	400w	1500	2.55N.m	7.6N.m
KY80AS0404-15	48V	400w	1500	2.55N.m	7.6N.m
KY80AS0204-30	24V	400w	3000	1.27N.m	3.8N.m
KY80AS0404-30	48V	400w	3000	1.27N.m	3.8N.m
KY80AS0407-30	48V	700w	3000	2.3N.m	6.9N.m
KY110AS0205-15	24V	500w	1500	3.18N.m	9.5N.m	110mm
KY110AS0207-15	24V	700w	1500	4.7N.m	14.1N.m
KY110AS0408-15	48V	800w	1500	5.0N.m	15N.m
KY110AS0210-15	24V	1kw	1500	6.3N.m	18.9N.m
KY110AS0410-15	48V	1kw	1500	6.3N.m	18.9N.m
KY110AS0412-25	48V	1.2kw	2500	4.5N.m	13.5N.m
KY110AS0415-15	48V	1.5kw	1500	9.5N.m	28.5N.m
KY110AS0415-30	48V	1.5kw	3000	4.7N.m	14.1N.m
KY110AS0420-25	48V	2kw	2500	7.6N.m	22.8N.m
KY130AS0410-15	48V	1kw	1500	6.3N.m	18.9N.m	130mm
KY130AS0415-15	48V	1.5kw	1500	9.5N.m	28.5N.m
KY130AS0430-15	48V	3kw	1500	19.1N.m	57.3N.m
KY130AS0430-30	48V	3kw	3000	9.5N.m	28.5N.m
KY200AS0450-15	48V	5kw	1500	31.8	63.6	200mm
KY200AS0975-15	96V	7.5kw	1500	47.7	95.4
KY200AS09100-15	96V	10kw	1500	63.6	127.2
KY215ACS0440-15	48V	4kw	1500	25.5	76	215mm
KY215ACS0460-15	48V	6kw	1500	38.2	110
Encoder: 2500ppr, optical, if you need other specificaiton, please advise.
Brake: if you need brake, kindly advise.
Accept custom-made motor, please contact us for more information.

• Applicatin




This pmsm motor has been widely used for many applications, eg., Mobile robot, Automatic Guided Vehicle,smart self driving robot vehicle platforms/kits,caterpillar lifting platform,Fire fighting Robot etc. It has better performances than other traditional dc motors.

2.

Q: How long have you been in this field?

A: More than 23 years in this field.

3.

Q: Do you have your own R&D team?

A: Yes. R&D is our core competitiveness, continuous innovation is just what we are seeking for all the time. Some of our engineers have more than 20years experience in the industry, and we also cooperate with colleges, scientific research institutions and large enterprises.

4.

Q: How soon can you deliver the goods?

A: That depends on the exact model you order. For regular products, usually we will prepare some units in stock, we can deliver them within 3 working days.

5.

Q: Can you make the product according to customer’s requirements?

A: Yes, welcome costom-made products.

6.

Q: What is your payment term?

A: You can pay by TT, Paypal, Western Union.
