Keya KY96BL04035-15 Joint Motor: Redefining Precision in Humanoid Robotics

The Evolution of Humanoid Motion: Why Joint Motors Matter

Humanoid robots performing delicate surgical tasks or industrial assembly require actuators that balance 26N·m instant torque with ±0.05° positioning accuracy. Keya’s KY96BL04035-15 permanent magnet synchronous motor (PMSM) delivers this duality, powering next-gen robots for healthcare, logistics, and collaborative manufacturing.

5 Competitive Advantages of Keya Joint Motors

1. Military-Grade Protection System

• 7-layer safety protocols:

• Overcurrent cutoff (20A threshold)

• Anti-jamming detection (200ms response)

• Voltage compensation (28-60V adaptive range)

• Tested: 10,000 emergency stops without performance degradation

2. Space-Saving Powerhouse

• Compact dimensions: Ø96mm × 135mm

• Power density: 423W/kg (350W/0.825kg)

• Case study: Reduced knee joint module size by 37% in bipedal robots

3. Ultra-Precise Motion Control

Application Spotlight: Surgical Assistance Robot

Challenge

• Lift 5kg instruments with 0.1mm tremor control

• Sustain 18-hour continuous operation

• Ensure zero electromagnetic interference (EMI)

Keya Solution

1. Deployed 4× KY96BL04035-15 motors (shoulders/elbows)

2. Operational configuration:

• Precision mode: Position control (0.05° repeatability)

• Power mode: Torque control (26N·m peak)

3. Integrated 12kHz PWM minimizes EMI

Results

• 99.98% motion accuracy (ISO 9283 certified)

• 40% longer lifespan vs. brushed DC competitors

• Natural cooling system maintained <45℃ during marathon surgeries

Technical Specifications Breakdown

Why Engineers Trust Keya

1. Zero Maintenance Design

• Brushless PMSM technology eliminates carbon wear

• IP22 rating resists dust in industrial environments

2. Dynamic Response Mastery

• 30-pole design ensures smooth 1550RPM operation

• Torque fluctuation <1.5% at 300RPM

3. Customization Flexibility

• Supports 4 control modes: Speed/Torque/Absolute/Relative Position

• Optional EtherCAT interface for Industry 4.0 integration

For OEM customization or bulk orders, contact Keya’s robotics division at contact link
